STRATAGLASS

Coated Scratch-Resistant Clear Vinyl

Strataglass is crafted from premium raw materials, protected with proprietary surface coatings, and manufactured using advanced processes to deliver exceptional clarity and long-term durability. Each sheet is thoroughly tested, and only those that meet our strict performance standards are certified as genuine Strataglass.

Get More Information
StrataHomeTop
StrataPage_1
Overview

About Strataglass

Strataglass® VueShield™ is a highly engineered, scratch-resistant coating technology that enhances clear visibility. This proprietary coating makes the product resistant to minor scratches and swirl marks that are common on clear vinyl products in harsh marine environments. Strataglass® VueShield™ offers additional UV resistance to protect the boat, passengers, and furnishings from the sun’s harmful rays. Strataglass® VueShield™ seals and protects Strataglass, maintaining its optimum durability and flexibility, and extending the product's life.

Strataglass is engineered with a proprietary anti-glare additive that enhances clarity, reduces sun glare, and improves low-light visibility.

Strataglass will have a useful marine life of 2-5 years when properly cleaned and maintained using Strataglass Protective Cleaner and Strataglass Protective Polish by IMAR, as directed by the manufacturer.

Scratch-Resistance

Made with a highly engineered, superior scratch-resistant coating called Strataglass® VueShield™, our proprietary surface treatment prevents fine-line scratches common to other inferior products. Our proprietary surface treatment seals and protects the composite, maintaining its optimal durability and flexibility, and extending the life of the Strataglass panels.

StrataPage_2
StrataPage_3

Resistance to Contaminants

Inferior clear vinyl products are prone to streaking from brass grommets on your Bimini top or runoff points of your boat top. These contaminants can become etched in, causing permanent imperfections in your enclosure panel. Our highly engineered Strataglass® VueShield™ surface treatment chemistry resists etching by these elements on the surface of your Strataglass Clear enclosure.

Strataglass Longevity

The benefit of our unique fusion of raw materials, precision manufacturing and VueShield™ surface treatment is obvious, you will see more clearly through your marine enclosure for a longer period of time. The exceptional Total Cost of Ownership of our solution delivers to you an increased useful life of your marine enclosure and reduces the frequency of expensive replacement common to other products.

StrataPage_4
StrataPage_3

Built for the Marine Enviroment

Strataglass is engineered for a smaller environmental footprint. Its base composite uses 50% less energy to produce than polyester and 670% less than corn-based PLA. Because it is lightweight, it also requires less fuel and generates fewer emissions during transport. The efficient manufacturing process further reduces impact, emitting 30% less CO₂ than polyethylene, 120% less than polyester, and 260% less than aluminum.

Download and View Product Specifications and Certifications

Product Resources
SPECIFICATIONS

Strataglass

Thickness 30 mil. 40 mil. 60 mil.
Sheet Size 54” x 110” 54” x 110” 54” x 110”
Tensile Strength ASTM D6693 4000 lbs. / in. 4000 lbs. / in. 4000 lbs. / in.
Light Transmittance ASTM D1003 90.6% 90.6% 90.6%
Haze ASTM D1003 1.0% 1.0% 1.0%
Hydroburst ASTM D751/A 150 PSI 150 PSI 150 PSI
Dimensional Stability ASTM D1204 <1.4% Change <1.4% Change <1.4% Change
UV Blocking HERC PE-P-3 >98% UVA >98% UVA >98% UVA
Flame Resistance CSFM Reg. Title 19 Pass Pass Pass
Flame Resistance NFPA 701 Test 1 Pass Pass Pass
Compliance Prop 65 (Phthalate Free) Yes Yes Yes
Cold Flex (no hydrostatic) ASTM D751 Passed -20 and -40 Passed -20 and -40 Passed -20 and -40
